CONSTRUCTION
- Vacuum infused hull, deck and roof
- Polyester and high quality anti-osmotic resin
- Balsa core hull, solid laminate under water line
- Grey gelcoat hull [Ral 7004]
- Balsa core bridge deck and roof
- Laminated or marine plywood bulkheads
SAILS
- 1 square top mainsail in Dacron® with battens, horizontal cut [color: grey]
- 1 self-tacking jib in Dacron® on furler with orange UV protective band
RIGGING [Standing & Running]
- Anodized aluminum mast
- 2 spreader bar rigs
- Deck light and steaming light on mast
- Square section mast pillar in galvanized steel, with linings
- Anodized aluminum boom
- Anodized aluminum crossbeam with fixing point for the jib furler and the davit
- Encased lower shrouds
- Forestay with furler for self-tacking jib
- Adjustable lazy-jack
- 2 shroud chainplates and 1 forestay chainplate on transversal beam
- Double braided mainsail halyard - polyester [Dyneema® soul]
- Double braided self-tacking jib halyard - polyester [Dyneema® soul]
- 2 mainsail sheets, pre-stretched - polyester
- 1 self-tacking jib sheet, pre-stretched - polyester
- 3 reef lines, pre-stretched - polyester
- 1 self-tacking jib furler line, pre-stretched - polyester
- 1 mainsail track line, pre-stretched - Technora®/Dyneema®
DECK HARDWARE [Winches & Gear]
- 1 manual winch size 50.2 STA
- 1 electric winch size 50.2 STA
- 1 electric FlatWinder™ [Harken]
- Mainsail track and ball bearing car
- 2 mainsail track rope clutches
- 1 self-tacking track for jib sheet with rope clutch
MOORING
- Composite longitudinal crossbeam with integrated chain run and 1 mooring cleat
- 2000W electrical windlass [12mm chain]
- 8 mooring cleats
DECK EQUIPMENT
- 2 flush deck hatches T60 for access to bow lockers
- 6 flush deck hatches T10 with vent
- 4 flush deck hatches T44
- 1 opening hatch integrated in roof forward window
- 2 opening hatches integrated in roof side windows
- Sliding door - 4 leaves (2 fixed and 2 sliding leaves)
- 2 escape hatches under the stairs
- 8 aluminum stanchions [color: Titanium] - 610mm
- Double textile lifelines in grey Dyneema® [high row: fluorescent plaits]
- Stainless steel handrail on roof
- Stainless steel handrails on transoms
HELM STATIONS
- Main helm station on starboard:
- Aluminum helm column
- GRP console for electronics
- Leather covered steering wheel and brake [800mm]
- 2 engine panels
- Mechanical engine throttles
- Compass on deck
- Double helm foldable seat
- Halyards and sheets storage
- Secondary helm station on port:
- Aluminum helm column with handrail
- Leather covered steering wheel and brake [800mm]
COCKPIT
- L-shaped bench on port with underseat storage
- Polyester cockpit table
- GRP furniture on starboard with:
- Sink
- Corian® countertop [Ash Concret]
- Coin tray and cup holders
- Double door and shelves
- Lazy boy on starboard with large storage locker
- Seats on aft beam with storage lockers
FOREDECK
- Trampoline with grey nylon thread
- Large sun pads area
- 2 GRP hatches for storage and technical access
- 2 Nuova Rade hatches
- Ladder for roof access
TRANSOMS
- Stainless steel swim ladder [starboard]
- Hot/cold fresh water deck shower [starboard]
- Pair of stainless steel davits with manual winch
