41 Custom 2024 Boat For Sale

• Beam: 12' 5''
• Hull Material: Composite

The Retro 41  is the first of a new generation of cruising yachts from Mark Mills which was designed to provide the owner with the ability to sail beautifully fast!

The yacht’s deck layout allows her to be controlled by a couple for cruising or with just a few adjustments she can be in race winning mode for any regatta, IRC/ORC or Spirit of Tradition classes.

The high-quality interior is of a simple but elegant design, featuring white panelling with varnished Teak trim that provides a clean bright look and easy maintenance.

• Epoxy composite sandwich hull and deck construction.

• Hull vacuum infused in a female mould.

• Deck vacuum infused in a female mould

• CoreCell M foam for Hull/Deck and PVC foam bulkheads.

• Biaxial and uni-directional carbon and E-glass fabrics with high density core blocking.

• built to ISO 12217 Plan Approval.

• Keel floors, case, and mast step moulded composite.

• Steel fabricated lifting keel fin.

• 2400kg antimony/lead bulb.

• Bonded hull to deck joint with flush mount Rails, Stanchions & hardware.

• Permateek toe rail to ORC requirements.

• Composite structural bulkheads bonded to hull and deck.

• Molded engine bed.

• Recessed hatch garage.

• Halyards recessed into coachroof.

• Opening transom door.

• Opening hatches above transom space.

• Cockpit seats and cockpit floor in teak.

• Cockpit rail in teak



• Yanmar 30hp 3 cylinder, diesel engine with saildrive, fresh water cooling, fuel filter & 80

  amp alternator.

• Molded composite engine surround with 25mm engine insulation for sound-proofing.

• Yanmar C30 recessed engine instrument panel.

• Low profile Morse-type manual gearshift and throttle.

• 60 litre fuel tank

• Gori - three bladed folding prop.

• Balanced spade rudder with carbon fiber stock and self-aligning roller bearings.

• Custom Edson Steering wheel mounted on pedestal - teak, holly, carbon laminate.

• Alloy emergency tiller.



• 200 litre total water capacity.

• Electric Marine head with macerator and individual 20 litre holding tank.

• Hot & cold pressure water system.

• Water heater 12 liter tank heated from engine.

• Head shower with sump pump.

• Manual bilge pumps in cockpit and below decks.

• Electric bilge pump.



      • Four Harken electric winches:

• Harken deck hardware as shown on deck plan.

• Spinlock Rope Clutches and stoppers.

• Stainless double rail open bow pulpit and stern rails.

• Stainless steel lifeline stanchions.

• Flush foredeck hatch, Lewmar size 60.

• Two Lewmar Size 1 opening ports.

• Lexan companionway sliding hatch.

• Swim ladder.

• Carbon mast – 2 sets swept Carbon spreaders / no runners.

• Carbon boom.

• Discontinuous rod rigging and turnbuckles.

• Double masthead spinnaker halyard sheaves.

• Double genoa halyard sheaves at hounds.

• Two genoa halyards.

• Two spinnaker halyards.

• Main halyard.

• Mainsheet hydraulics – Harken

• Traveler control lines.

• Two mainsail clew reef lines.

• Carbon-fiber bowsprit.

• Tack line.

• Two spinnaker sheets.

• Two genoa sheets.

• Backstay hydraulics – Harken

• Solid Mechanical Vang.

• Custom Carbon chain plates and backstay tang.



• 24V electric system (Mastervolt components).

• Mastervolt Alpha Alternator.

• Mastervolt MLI Ultra Lithium Battery 24/6000 – 6 kWh.

• Mastervolt Mac Plus DC/DC Converter Charger 24/12–50.

• Mastervolt CombiMaster Inverter/Charger 24/300070

• CZone Control.

• CZone Waterproof Keypad.

• Czone Touch.

• Blue Sea Systems Circuit Breakers.

• Battery condition meter.

• AC/DC electrical panel.

• shorepower system.

• 12 VDC refrigerator.

• LED Navigation & steaming lights.

• swivelling white LED lights.

• red/white LED dome lights.

• Chart Light.

• Polished stainless sink recessed in counter top.

• Front opening refrigerator under.

• propane gas bottle in cockpit locker connected through shutoff valve.

• Pressure water pump.

• Swivel faucet pressure water.

  Interior

• Door into enclosed head to port with door forward into stateroom.

• Hanging locker P&S, lockers

• Large double V-berth, drawers for storage underneath.

• Enclosed head, dual purpose shower/sink spigot, and door.

• Ceilings in saloon/head and forward stateroom painted tongue and groove

• Varnished teak & holly veneer sole with removable panels.

• Main cabin settee berths with cushions, stowage under.

• Port and Starboard grab rails in main cabin.

• quarter berth aft to port and starboard.

  Finishes

• Hull fared and painted with Awlgrip

• Interior off-white satin epoxy with wood trim around openings; lightweight bunk tops

  with white finish; wood drawer and cabinet trim.

• Side decks & cockpit synthetic teak

Launched in December in Slovenia ( see below vidio)  for a U.S. client, this performance design combines the casual elegance of an east coast day sailer with the power and speed of a dedicated racer to produce the ultimate weekender.  Laid out for shorthanded day sailing the light displacement, large sail plan, and deep keel can deliver race boat levels of performance when desired, but will always give fast smooth good manners.  Bringing the high quality prediction tools we have developed on our successful race boats to a performance cruiser/racer gives owners a level of assurance regarding handling and performance that modern classic designs have not seen before.

Drawn with one eye on the classic day sailers of the U.S. east coast, we blended the styling with a modern hull shape derived from our latest racing designs, and emphasised the basic components of high performance, starting with the longer waterline provided by a plumb bow, improving the speed potential by around 15% for the same LOA relative to an overhanging bow.  The hull shape maintains low wetted surface at smaller angles of heel for good light-air speed, but gains stability quickly when heeled.  This combines with the deep lifting keel to ensure high stability without heavy displacement.  Bringing in engineering partner SDK to produce high quality composite engineering was key to ensuring a stiff light structure.

The distribution of space on board reflects the weekender brief from the client: a focus on comfortable high performance day sailing combined with the ability to spend a few nights on board, perhaps in a scenic anchorage.    This inspired the large open cockpit with a 4 winch layout allowing two to sail the boat easily, many more to cruise and socialise comfortably, or when racing with friends to compete successfully even offshore.  The svelte coach roof offers the necessary headroom over the sizable saloon and galley, without visually compromising the sleek simplicity of its day sailor heritage.

The carbon mast and park avenue boom ensure the lightest weight and lowest VCG, which with the long fixed bowsprit carries a balanced yet powerful sail plan.
