DECK & HULL:

Construction of the hull is Hinckley DualGuard® Composite Construction Kevlar E-glass hybrid outer skin. Aircraft grade end-grain balsa below the waterline. Carbon-fiber inner skin. SCRIMP® laminated with vinylester resin. Deck and cockpit are E-glass with balsa and closed-cell foam core, SCRIMPED with vinylester resin.

Awlgrip Flag Blue topsides
Cream gelcoat cabin house and deck
Single Cordovan Gold bootstripe
Micron Extra Black bottom

Marelon ball-valve seacocks with thru-hulls below water line and Marelon thru-hulls above the waterline
Stainless steel half round on fiberglass molded rub rail
Stainless steel swim handle on transom painted to match hull

Heavy-duty fiberglass swim platform has teak insert treads, stainless steel bracket and half round

Stainless steel telescoping 3-step folding swim ladder that stores under platform

Deck Features:

Flush foredeck anchor locker with hinged hatch and fold-out anchor roller.
Rounded, tapered, varnished teak toe rail with Hinckley profile
Two additional pad eyes each side fore & aft of the midrail cleats
Varnished teak eyebrow molding around cabin top
Varnished teak handrails on house top, cabin and aft end of pilothouse
Four (4) elliptical opening ports on house sides with screens
Hinckley pilothouse mast with spotlight, Radome painted to match deck.
Large side windows in Pilothouse open electrically
(2) Stainless Steel electric opening hatches in the Pilothouse with powered Ocean Air Sky Screens
Custom Hinckley 316L stainless steel bow chocks
Bow, stern and 316L stainless steel mooring cleats - mid-rail easily reached from cockpit – pop-up mid ship cleats
Fender padeyes with toe rail chafe strips
ACR spotlight - Masthead mounted with helm mounted electric remote control

COCKPIT:

The cockpit features cushioned seating at the transom with filler piece in front of transom door. Aft facing seats are located at the forward end of the cockpit.

Teak deck, interior and teak cockpit coaming.
Starboard transom door from swim platform

Teak boarding step for port or starboard side deck

Courtesy lights under side decks port and starboard

Cockpit/pilothouse lockers with varnished louvered teak doors
Cockpit shower with mixing valve at stern seat.
Fishing rod holders port and starboard with rod storage under port side deck.
Ivory Stamoid cockpit cover

PILOTHOUSE:

The Pilothouse is fully air conditioned

Teak finished pilothouse deck, upper sides and dash.
(4) Pilothouse windows with Green Tint include: (2) Electric Sliding side windows and (2) Fixed, forward with heavy duty, self-parking, intermittent windshield wipers and fresh water washers.
Ivory Ultraleather helmsman and passenger seats.
Ermine Ultraleather cockpit and pilothouse cushions
Pilothouse dining table with flip down leaves; removable with storage bag
Insulated white overhead has two (2) Electric opening hatches with Ocean Air Sky screens/shades
20,000 BTU air conditioning powered by onboard generator or shore power.
Additional illumination is by four (4) overhead low-voltage halogen lights.
Storage lockers under pilothouse settees
(5) Cup holders
Varnished teak locking companionway door with companionway lid stay

(2) Varnished teak handrail on centerline
Ivory Stamoid 5-piece drop curtains with Eisenglass windows
Refrigerator mounted in starboard amenity.
Portside amenity has built- in self draining drink cooler with stowage underneath.
Icemaker installed in port amenity between cockpit and pilothouse
110VAC and TV outlets.

Helm Station:

Varnished teak instrument pod
Stainless steel 14” steering wheel with varnished wood rim
Hinckley JetStick with H-Lock and Heading Hold
Engine gauges, tachometer with hour meter, oil pressure, water temp., nozzle indicator
Top-opening locker with chart storage
12-volt “cigarette style” outlet in chart pocket
Varnished teak binocular holder

ELECTRONICS AND NAVIGATION EQUIPMENT:

Navigation Equipment:

Raymarine Hybrid Touch Chartplotter, GPS, Radar with Sirius satellite weather
Raymarine autopilot
Icom M604 VHF radio and Commandmic III
Sirius Satellite Weather receiver
24” HD Scanner

Entertainment Equipment:

Alpine stereo system with Sirius Satellite radio, Bluetooth, AM/FM, Pandora
(3) Pair of speakers – In V-berth forward bulkhead, pilothouse. Forward and pilothouse speakers have remote volume control
Ipod/MP3 audio input jack at helm
22” Sole’ HD LCD TV with DVD player
KVH M1 Satellite TV system with Direct TV network. Dome painted to match deck
Onboard MiFi System

ACCOMMODATIONS & LAYOUT:

Galley:

Aurora Corian countertop
Stainless steel sink with Grohe fixtures, spray nozzle and hot and cold pressure water.

Adler Barbour refrigeration – 12-volt cold plate refrigerator in a self-draining insulated box
Single electric burner cook-top with Corian cover
600-watt 110-volt microwave oven
110-volt outlet
Built-in bin for dish stowage
Custom glass storage on shelf above microwave.
(3) Cherry pullout drawers
Red step-light in galley
Under counter pull-out garbage receptacle
Opening port with screen
Additional storage is provided outboard and under the galley sink.

A “pantry” locker with louvered door and several shelves separates the galley from the forward V-berth area and houses the stereo system.

V-Berth:

A very comfortable Queen berth is formed with an insert.
V-berth upholstered in Ermine Ultraleather
Varnished cherry shelves over berths outboard

Storage lockers under V-berth has easy-access cherry drop-front doors.

Cedar-lined hanging locker is just aft of the V-berths to starboard.
(2) Stereo speakers are mounted port and starboard on the forward bulkhead.
(2) Hella fans – port and starboard bulkhead facing aft.
Overhead opening hatch with Ocean Air Sky screen/shade.

Head:

Solid cherry door panel door
Molded fiberglass sole for easy cleaning.
Varnished Cherry countertop and under-mounted porcelain sink.
Grohe faucet/hand held shower provides hot & cold pressure water – bracket for shower bulkhead mounted
Sealand Vacu-Flush electric marine head is plumbed to a 27-gallon aluminum holding tank and overboard discharge
Mirror on the forward bulkhead with cherry frame.
Storage is provided by cherry faced lockers above and outboard the vanity, a drawer with a cherry face beside the marine head, and a locker under the vanity.
110-volt outlet
Opening port with screen, as well as forced ventilation.
Stainless steel towel bar

ELECTRICAL SYSTEM:

Low resistance, copper wire and sacrificial zinc anode bonding system. Zinc saver.

12-volt system:

(3) 12-volt batteries for a total of 540-amps.
Start – Two 12-volt AGM Group 31 batteries with 950 CCA capability.
House – Two 12-volt AGM Group 4D batteries – 210-amps each.
Heavy-duty battery parallel switch allows emergency starting.
80-amp battery alternator on engine.
12-volt distribution panel includes thermo-magnetic breakers, volt and amp meter.

110-volt AC electrical system

110-volt shore power inlet and relay.
50-amp shore power cord with Glendinning retractable power cord.
Victron Multiplus inverter/charger with 100-amp 12-volt multi-stage battery charging capability.
Onan 9kW generator and sound shield

MECHANICAL EQUIPMENT & ENGINE DETAILS:

Yanmar 8LV 370 hp diesel engines. Port engine (2024) with 34 hours; 596 STBD engine hours

Hamilton 274 Jet Drives
Twin ZF 63 transmissions
7” hydraulic variable thrust bow thruster
Hinckley JetStick control system with Hover Lock and Heading Hold
Dual cylinder trim tabs with indicator controls at helm
Fuel filter/water separator
Agea-X Fuel polishing system for main engines and generator
Groco Metal raw water engine strainers in lieu of plastic strainers
Oil change kit
Volvo EVC Tachometer with LCD multi-function display
Fuel, oil pressure, and water temperature gauges.
Alarms for high-low oil pressure, and high engine water temperature and hydraulic pressure.

Manual hydraulic steering pump.
(3) Electric 1500-GPH 12-volt bilge pumps with float switches and high water alarm
High pressure deck wash pump
Whale emergency bilge pump - mounted in cockpit locker.
In-line 12-volt automatic shower sump pump.
27-gallon aluminum holding tank with overboard discharge.
6-gallon stainless steel hot water heater – shore power and engine heated.
40-gallon polyethelelene water tank.
(2) 110-gallon polyethelene fuel tanks - total 220-gallons.
Mylar-faced acoustical foam-lined engine box insulation.
Engine box cover has double gaskets and an electric riser.
Engine box forced-air exhaust fan.
Baffled and insulated air intake
Automatic engine compartment fire suppression system, with automatic engine shut-down.

ADDITIONAL EQUIPMENT:

Muir electric windlass pkg: Flush foredeck anchor locker houses a Muir electric windlass with polished stainless steel Delta 22# anchor + 15’ stainless steel chain & 150’ anchor rode and polished stainless steel folding bow roller. The windlass can be operated from the helm station or a handheld wired remote at anchor locker.

Stern mounted 4 ft. varnished teak ensign pole & flush socket
Stamoid Ivory mooring cover
Boat hook - mounted under side deck.
Dock lines
Fenders with fleece covers
Deck shower/water outlet with hot & cold mixing valve.
Life jackets
Fire extinguishers
Liferaft
Siren Marine monitoring system
EPIRB
12-volt trumpet air horn with switch on dash.
Masthead and running lights
