IONIAN PRINCESS Yacht for Sale

• Cruising Speed: 12 kn
• Maximum Speed: 18 kn
• Beam: 28' 0''
• Hull Material: Other
• Max Draft: 8' 10''
• Fuel Tank: 1 x 9312|gallon
• Fresh Water: 1 x 1500|gallon
• Holding: 1 x 1447|gallon
• Max Passengers: 12
• Cabins: 11
• Heads: 13

MAIN SPECIFICATIONS

Length Overall: 150’ (45.72m)

Length at Waterline: 139’9 (42.59m)

Beam: 28’ (8.53m)

Min Draft: 7’10” (2.39m)

Max Draft: 8’ 10” (2.69m)

Year Completed: 2005

Model Year: 2005

Refit: 2022/2024

Type: Motor Yacht

HIN: 0018

Tonnage: 416

Displacement: 266.87 LT (long tons)

Hull Config: Semi-displacement

Guests: 12

Crew: 9

CONSTRUCTION

Builder: Christensen

Naval Architect: Christensen Shipyards, LLC

Exterior Design/Stylist: Setzer Design Group/Fernando Torres

Interior Design/Stylist: Pavlik Design Team/Fernando Torres

Hull Material: GRP

Deck Material: Teak

Classification: AMS ABS

SPEED

Maximum: 18 knots

Cruising: 12 knots

Economical: 10 knots

Range: 2000 @ 12 knots

Consumption @ Max: 145 US gallons p/hr

Consumption @ Cruising: 124 US gallons p/hr

Consumption @ Economical: 52 US gallons p/hr

CAPACITIES

Fuel: 9,312 gallons / 35,249 liters

Water: 1,500 gallons / 5,678 liters

Grey Water: 499 gallons / 1,899 liters

Black Water: 1,447 gallons / 5,477 liters

Lube Oil Capacity: 150 gallons / 567 liters

Waste Oil Capacity: 150 gallons / 567 liters

CLASSIFICATION & CERTIFICATIONS

Flag: Jamaica

Classification: AMS ABS

MACHINERY

MAIN ENGINES

Engine Type: 2x Caterpillar C-32 ACERT Diesel

Horsepower: 2x 1900

Engine Serial Numbers: Port – RPM01139; STBD – RPM0114

Main Engine Hours (Port): 122

Main Engine Hours (Stbd): 122

GENERATORS & ELECTRICITY

Output: 380 Volt 50 HZ 3-phase

Generators: 2x Caterpillar 85 kW – turbo-charged (Gen # 1 & 2) & 1x Caterpillar 50 kW – naturally aspirated generator (Gen #3)

Generator Fuel Consumption: 85 KW - Turbo charged generator consumption = 7.4 Gal/ hr or 28.1 Lit/hr

50 KW - Naturally aspirated generator consumption = 5.2 Gal/hr or 19.7 Lit/hr

Generator #1 Hours (85kW): 27,923

Generator #2 Hours (85kW): 9,490

Generator #3 Hours (50kW): 9,781

Shore power: Atlast Marine Systems, Inc – Model SPA-90F

Generator Starting: 24 VDC

BATTERIES

Batteries: 4x 8D AGM

Generator Starting: 4x 8D AGM

Emergency: 8x ODX – AGM-31M

PROPULSION & STEERING

Drive: Shaft propeller

Gearboxes for Main Engines: ZF BW46S

Stabilizer: Quantum/Naiad

Stabilizer Underway: Yes

Stabilizer at Anchor: Yes

Steering System: Anschutz

Emergency Steering System: Jastram

Helm Control: Jastram

OTHER MACHINERY

Water Makers: Blue Water Explorer

Bow Thruster: American Bow Thruster

Fuel Separator and Filtration: Alfa Laval MAB 103B/Racor Filtration

Sewage System: Headhunter Tidal Wave HMX MSD-Type II

Fresh Water System: 2x Headhunter Mach 5

Oily Water Separator: BilgeMon 488

Air Compressor: 7 Bar / 100 PIS

Air Conditioning: 380,000 BTU Titan Air

COMMUNICATION AND NAVIGATIONAL EQUIPMENT

SAT COM: SeaTell (Internet) / Starlink RV Internet

Satellite TV Systems: Nova

Telephone System: Panasonic PABX

SSB: Furuno FS-1570

VHF: 2x Furuno FS-1570

Cellular Phone System: GSM

Intercom: Raytheon ray 430 Loudhailer

Iridium: Thrane/LARS LT-3100S

Navtex: Furuno NX-700

Radar: 2x Furuno 9 GHZ FR- 2115-B w/ ARPA

Gyrocompass: Anschutz

Magnetic Compass: Cassens & Plath

Auto Pilot: Anschutz

Depth Sounder: Furuno color LSD FCV-1200L

GPS: Furuno GP1871 F/Koden KGP-902

AIS: FA-150

Ships Computer: HP

Ships Printer: HP Office Jet Pro 9125e

Plotter: Nobeltec TimeZero

Wind/Speed Log: Simrad

Telefax: Fleet 77

Weather Fax: Furuno DFAX-207

ENTERTAINMENT SYSTEMS

Video Equipment: Crestron Remote Multi-system

TV's: Samsung Smart TV's throughout

Audio Equipment: Chameleon 64i/Denon/Arcam

DVD's: Sony

CD Player: Yamaha

iPod Stations: Apple iPod stations throughout

Misc.: (6) Blu-ray/Apple Tv/Apple mini

GALLEY & LAUNDRY EQUIPMENT

MAIN GALLEY EQUIPMENT

Cooktop: AEG 5 burner electric

Oven: 2x Miele

Microwave: 1x Sharp/1x GE

Refrigerator: 4x Liebherr

Freezer: 4x Liebherr Freezers

Additional Refrigerator/Freezer: 1x small fridge - Norcold

Dishwasher: Chef-King 50

Wine cooler: Phiestina

Icemakers: 2x Electrolux

CREW GALLEY/ MESS

Dishwasher: 1x Bosch

LAUNDRY

Washing Machines: 3x Speed Queen

Dryers: 3x Speed Queen

DECK EQUIPMENT

Anchor Windlass: 2x Muiri

Deck Capstans: 2x Maxwell 3500

Anchors: 2

Anchor Chain & Rode: 150 m x 2

Boat Crane and Davits: Nautical Structures HMC-1100 & Nautical Structures HMC-4000

Passarelle: Besenzoni

Accomm Ladders: 1x portable

Swim Ladders: 1x Stainless Steel w/ teak steps

Exterior showers: 2x on swim platform

TENDER & TOYS

Tender: 16' Nautica Yamaha 70 4-stroke

(2) Waverunners: (2) Yamaha 1200 CC

(2) Kayaks

Note: Subject to change and/or negotiation during the buying process.

SECURITY, FIRE FIGHTING AND SAFETY EQUIPMENT

SECURITY

Cameras: 6

Monitors: 8

Fire/Heat/Smoke Detectors: New Tyco System - throughout

Fixed FM 200 System: 1

Portable CO2: 5

Fire Extinguishers: 36

Seawater Firefighting Station: 6

Life Rafts: 4x Viking 12-persons in canisters/hydrostatic release

Life Rings: 5

EPIRB(s): 1x 406 MHZ Automatic/Manual ACR GlobalFix V4

SART: 2x ACR Pathfinder Pro’s

Flares: Handheld, orange smoke, and parachute flares

ACCOMMODATION AND LAYOUT

12 guests in 6 cabins

9 crew in 5 cabins including captain’s cabin

REFIT 2021/2022

Machinery

● New Caterpillar C-32 ACERT 1900 HP

● Caterpillar Generators - x2 85kw, x1 50kw

o New long blocks and rebuilt electrical power packs

● AC System: The system was replaced by Titan Marine: Chillers, air handlers, and plumbing

● Atlas System: Refurbished 2021

● Hydraulic system - Overhauled: PTO's were rebuilt, new hydraulic hoses and intercoolers were rebuilt

● Stabilizer system - Overhauled: Pump and hydraulic motor rebuilt

● Freshwater system- Pumps replaced

● Waste Treatment system- NEW

● Diaphragm pumps - Overhauled: All pumps were rebuilt

● Exhaust system: NEW DeAngelo's

● ER plumbing: Overhauled

Exterior

● The bottom was soda blasted at Roscioli (2020) with a new barrier coat applied, and the bottom paint was applied by compressed air spraying.

● Running gear (2020): Stabilizer seals, shaft seals, rudder shaft seals, and cutlass bearings were replaced.

● Through hulls were all replaced or serviced.

● All overhead panels on the main deck, bridge deck, and sundeck were repainted

● All Countertops were replaced

● The Foredeck non-skid was repainted

Interior

● The interior of Ionian Princess was completely reimagined in collaboration with the owners and Yacht next. All items listed are newly installed.

● Headliners throughout

● Interior furniture

● Carpet throughout

● Custom bedroom furnishings in all staterooms

● New wall finishings in all staterooms and ensuites

● Interior lighting was converted to LED

● Pilothouse - helm chairs and settee reupholstered

● Captain's cabin - modernized

● Crew quarters - modernized

● Galley - All new cabinetry, countertops, lighting, and refrigeration

REFIT 2023/2024

Machinery

● Main engine overhaul / manufacturing certification

● Main engine block heaters installed

● 3 x generators serviced and reconditioned

● Air-conditioning systems and plant reconditioned

● Air-conditioning insulation renewed chill water loop

● New Tyco fire system installed

● Alfa Laval fuel polishing system reconditioned

● Bow thruster inspection and calibration

● Engine Room CO2 inspected and reconditioned

● Emergency fuel shut-off system upgraded

● New fire pump installed

● AC Bilge pumps reconditioned

● Emergency fire / bilge pumps reconditioned

● Sundeck and bow cranes rebuilt and reconditioned

● Tanks inspected, and new sensors installed

● Windlass & anchors removed and reconditioned

● Oily water calibrated and reconditioned

● Stabilizer rams & control heads reconditioned

● Steering systems reconditioned

● Thru-hulls replaced throughout the vessel

● New valves installed in engine room

● Grey water pumps rebuilt & headhunter auto pumping installed

● Atlas power unit reconditioned & new cooling system installed

● New emergency battery banks installed

● New main engine & generator batteries installed

● Electrical systems reconditioned

● GMDSS equipment was reconditioned & new iridium installed

● Exhaust systems inspected

● Running gear inspection

● Sea chests - fiberglass tubing replaced

● New zincs installed

● Rudders & propellers - new prop seed coating

● Bottom paint - touched up

● Bridge windows re-sealed

● Prop crack test - passed

● Rudder bump test - passed

● Bow thruster grates reconditioned

Exterior

● All watertight doors & hatches reconditioned

● Exterior overheads - Velcro replaced & mounts replaced

● Deck stanchions - New gaskets & remounted

● Non-Skid redone all 3 decks

● Varnish on cap rails recoated

Interior

● Interior overheads - Velcro replaced & mounts replaced

● Twin cabin mirror replaced

● New smart Tv’s installed

● New Apple TV’s installed
