KATIE B Boat for Sale

• Cruising Speed: 23 kn
• Maximum Speed: 27 kn
• Beam: 11' 4''
• Hull Material: Fiberglass
• Max Draft: 1' 10''
• Displacement: 17,000 lb
• Fuel Tank: 1 x 220|gallon
• Fresh Water: 1 x 40|gallon
• Holding: 1 x 27|gallon
• Cabins: 1
• Heads: 1

HULL and DECK:

• Midnight Blue Awlgrip topsides
• Light Cream gelcoat cabin house and deck with painted nonskid.
• Single Matterhorn White Boot stripe
• Red bottom

CONSTRUCTION:

• Hull:  Hinckley DualGuard® Composite Construction Kevlar/E-glass hybrid outer skin with aircraft grade end-grain balsa below the waterline, and a Carbon-fiber inner skin.  Laminated with a vinylester resin (SCRIMP®).
• Deck:  E-glass outer and inner skin with aircraft grade end grain balsa and closed-cell foam core.  Laminated with vinylester resin using (SCRIMP®).
• Marelon ® ball valve seacocks with thru hulls below waterline and Marelon ® thru hulls above waterline.

• Swim Platform - Heavy-duty fiberglass swim platform with teak insert treads, S/S bracket and S/S half-round rubrail
• Quarterguard painted to match hull with stainless steel half round rubrail extends forward from swim platform to protect tumblehome
• S/S telescoping 3-step folding swim ladder that stores under swim platform

DECK:

• Rounded, tapered, varnished teak toe rail with Hinckley profile

• Stainless steel (S/S) half-round on fiberglass molded rub rail

• Flush molded, foredeck anchor locker with hinged hatch and fold-out anchor roller and shelf for windlass
• Varnished teak eyebrow molding around cabin top
• (5) Varnished teak handrails port and starboard on cabin top, port and starboard on pilothouse top and aft end of pilothouse
• Custom Hinckley 316L stainless steel bow chocks
• (2) 10” bow, (2) 10” stern cleats, (4) 8” pull-up spring cleats amidships all in type 316L S/S
• Three (3) deck mounted fender pad eyes each side with toe rail chafe strips
• One (1) low-profile polished SS cabin top hatch with retractable blind and screen
• Hinckley designed pilothouse mast on roof top with ACR spotlight, anchor light and VHF antenna
•  (4) Elliptical opening ports on house sides with screens
• Stainless steel bow rail provides security when anchoring or docking
• St. Croix stainless removable dinghy davits
• Anchor windlass in below deck locker with pivoting anchor bracket and flush deck fiberglass hatch

COCKPIT

• Varnished teak coaming and coaming cap
• Cockpit has seating that includes cushioned forward-facing transom seating and port and starboard aft-facing seats located at the forward end of the cockpit
• Removable transom seat filler with cushion at transom door
• Storage underneath all seating

• Direct overboard scuppers with SS grate covers

• Cockpit/Pilothouse amenity lockers with varnished louvered teak doors
• Port amenity has lift up lid with insulated wine cooler below
• Starboard amenity features a stainless sink with hot/cold water under hinged teak lid
• Hinckley designed flip-down boarding steps in port and starboard coaming
• Starboard transom door entry from swim platform
• Cockpit shower with hot/cold mixing valve at transom door
• Cockpit lighting  - white courtesy lighting port & starboard on dimmer under side decks and a cockpit steplight

PILOTHOUSE

• Varnished teak on interior pilothouse sides, instrument pod, and dash
• Varnished teak companionway door with bi-fold hatch and lock
• (2) Stidd Slimline helm electric up/down/fore/aft adjustable seats with footrests
• L-Settees - aft port and starboard with storage underneath.
• Removable varnished teak table with custom larger leaf and fixed polished SS pedestal with cover
• (2) Overhead oversized electric opening hatches in the Pilothouse roof with retractable blinds and screens
• Powered sliding side opening windows in concealed S/S frames with controls port and starboard and lockout safety switch

• (2) Fixed forward windows in concealed S/S frames

• Two (2) heavy duty and electric, self-parking wipers on Pilothouse windows, intermittent wiper control, fresh water windshield washers, and pad mounted control at helm

• (2) 12-volt outlets
• (2) Stereo marine speakers
• Accupoint heater outlets
• Additional illumination is by five (5) overhead low-voltage halogen lights on a dimmer switch.
• Stamoid/Eisenglass 3-piece drop curtains to enclose Pilothouse area

HELM STATION:

• Varnished teak instrument pod
• Stainless steel 14” steering wheel with varnished wood rim
• Hinckley JetStick® - integrates forward and aft motion, steering, and bow thruster into single joystick. First generation IQAN
• Engine gauges, tachometer with hour meter, oil pressure, cooling water temperature
• Top-opening locker starboard
• 12-volt “cigarette style” outlet at helm and in locker to starboard
• ACR remote controlled spotlight

ELECTRONICS - NAVIGATION PACKAGE

• Garmin GPSMap 8617 Chartplotter/Radar display
• Garmin GMR 24 HD radome painted to match rooftop

• Raymarine ST6002 Autopilot

• Garmin VHF 300 with GHS 10 remote mic at helm
• Mounted Ritchie compass

STEREO/ENTERTAINMENT

• Alpine iDA-X305 AM/FM stereo with Aux input
• Two (2) Alpine marine speakers in Pilothouse
• Two (2) Alpine marine speakers in interior forward bulkhead

INTERIOR

The interior is finished in satin-varnished cherry and an acoustic foam headliner with cherry trim. The cabin sole is varnished teak and tulipwood and has a custom cabin sole cover. Louvered cherry locker doors and (5) Frigast stainless steel bulkhead lights add to the cabin ambience.

• Accupoint heater – with outlets in pilothouse, main cabin and head

Entry is from the pilothouse bi-fold companionway to the Galley to port, private Head to starboard and the V-berth accommodations forward.

GALLEY (Port)

• Abalone Corian countertop
• Stainless steel under mounted sink bowl with Corian cover with single-lever fixtures, and hot and cold pressure water.
• Sea Frost refrigeration – 12-volt cold plate refrigerator in a self-draining insulated box
• Single burner Seward Princess one burner built in butane cook-top with wooden cutting board cover
• 110-volt microwave oven
• 110-volt outlet
• Built-in bin for dish stowage and cup stowage under the microwave
• (3) Cherry pullout drawers
• Red step-light in galley
• Under counter pull-out garbage receptacle
• Opening port with screen
• Additional storage is provided in companionway step, outboard and under the galley sink.

The stove is set in the countertop and has a custom stove cover that adds to the already ample counter space surrounding the sink.  The sink also has a Corian cover. Microwave is built in outboard. The refrigeration is mounted aft and is accessed by a counter lift-up top. A “pantry” locker with louvered door and several shelves separates the galley from the forward V-berth area and houses the stereo system.

HEAD (Next aft starboard)

• Solid cherry panel door
• Molded fiberglass sole for easy cleaning.
• Varnished cherry countertop with an undermounted porcelain sink.
• Grohe faucet/handheld shower provides hot & cold pressure water – bracket for shower bulkhead mounted.
• Sealand Vacu-Flush electric marine head is plumbed to a 28-gallon polyethylene holding tank (head new 2023)
• Mirror on the forward bulkhead with cherry frame.
• Storage is provided by cherry faced lockers above and outboard the vanity, a drawer with a cherry face beside the marine head, and a locker under the vanity.
• 110-volt outlet
• (1) Hella fan
• Opening port with screen

V-BERTH (Forward)

• Varnished cherry shelves over berths outboard

• Storage lockers under V-berth have easy-access cherry drop-front doors.

• Cedar-lined hanging locker is just aft of the V-berths to starboard.
• Additional storage under V-berths and 2-drawers under V-Berth seat
• (2) Stereo speakers are mounted port and starboard on the forward bulkhead.
• (2) Hella fans – port and starboard bulkhead facing aft.
• Overhead opening hatch with Ocean Air Sky screen/shade.

ELECTRICAL

• Victron Multiplus 12V/3000/120 pure sine wave inverter/charger with 100-amp 12-volt multi-stage battery charging capability
• Charles 30 amp battery charger for start batteries
• Glendinning retractable 50-amp 110/220 shore power cord with wireless remote
• Two (2) 12-volt AGM Group 31 starting batteries
• Two (2) 12-volt AGM Group 4D house batteries (2021)
• 12-volt Bass distribution panel using thermo-magnetic breakers with volt and amp meters
• Separate alternators for house and start batteries.
• Heavy-duty battery parallel switch allows emergency starting.
• Low resistance, copper wire and sacrificial zinc anode bonding system and zinc saver

SOUND REDUCTION

• Mylar-faced acoustical foam- varying densities -engine room insulation.
• Gaskets on deck hatches
• Custom fiberglass, baffled, insulated and drained engine air intake
• Sound absorbent material for Pilothouse and Cabin overhead

MECHANICAL EQUIPMENT

• Electric lift for Pilothouse deck gives full engine access with additional hatch for daily checks

• Twin Volvo 300-hp D-4 common rail diesel engines

• Hamilton 274 Jet Drives
• Twin ZF 63 transmissions
• Hinckley JetStick® with integrated control of steering, forward and aft motion and bow thruster
• 7” proportional hydraulic bow thruster

• Manual hydraulic steering pump
• Volvo EVC tachometer with LCD multifunction display for each engine
• Analog  gauges for engine oil pressure, engine coolant temperature, fuel gauge and volt meter
• Alarms for low oil pressure and high engine water temperature

• Racor fuel filter/water separator with vacuum gauges and water sensing alarms

• Engine room forced-air blower

• Dual-cylinder stainless steel trim tabs with indicator controls at helm
• Automatic engine compartment fire suppression system with automatic engine shut-down

• 12-volt DC automatic shower sump pump.
• Three (3) 1500-GPH 12-volt bilge pumps with safety float switches and high water alarm (float switches replaced 2022)
• Whale emergency bilge pump mounted in engine room
• Hot and cold pressure system
• Two (2) 110-gallon polyethylene fuel tanks with flush mount vents on hull sides and fuel/air separators
• 40-gallon polyethylene water tank with flush mount vent on hull side and remote gauge (new 2022)
• 6-gallon stainless steel hot water tank heated by shore power and engine
• 28-gallon polyethylene integrated holding tank with flush mount vent on hull side and pump out fitting on deck
• Accupoint Heater – ducts in pilothouse, main cabin and head.

ADDITIONAL EQUIPMENT

Ground Tackle System:

• Windlass package consists of Hinckley designed polished S/S folding anchor roller, Muir  hydraulic windlass operated from the helm station or a handheld wired remote at anchor locker, polished S/S Delta anchor with 25’ of S/S chain & 150’ anchor rode

Equipment:

• Bow varnished burgee pennant staff with socket in bow rail.
• Stern mounted 4 ft. varnished teak ensign pole & flush socket
• Boat hook - mounted under side deck
• Dock lines
• Three (3) fenders
• Life jackets
• Fire extinguishers
• Flare kit
• Masthead and running lights
• 12-volt Kahlenberg single trumpet air horn mounted on roof with switch on dash
