LADY ELKIE Yacht for Sale

New teak swim platform

3 new AC chillers

Out of Water survey - January 2025

Main Deck

• (5) Teak Steps up to Stern Gates in SS and Plexiglass with Manual Blocking System
• Sun Pad; Custom SS Rail was Added Around Aft Section for Safety
• Custom Cockpit Canvas Sun Shade
• Second Docking Station to Port with Engine Controls, Furuno Multi Function Display, Bow/ Stern Thruster Controls,
and ZF Electric Throttle
• Crew Quarters and Engine Room Access
• Fiberglass Cabinet Fitted with Sink Electric Grill, and Fridge
• L-Shaped Sofa to Port with Unfolding Teak Cockpit Table and seating for 8
• Watertight Loudspeakers
• 3-Person Helm Seat that electrically adjusts in height with Weatherproof TV Custom Mounted to the Back
• Sun Pad Lounge to Port
• In Deck Engine Room Hatch with Custom SS Slide-Out Handrail for Safety and Easy Entry to Engine Room
• (2) Warping 500W Winches with Mooring Cleats and Fairleads
• Massive Tempered Glass Windshield with Stainless Steel Roll Bar
• (2) Wipers with Built-In Washers and Timer

Helm
• ZF Throttles
• MTU Engine Gauges and Touch Screen Displays, Trim Tab Indicators, Compass
• (2) 17” Hatteland Displays for Plotter, Radar, and Depthsounder
• Furuno Black Box NavNet 3D
• Furuno FAP-7116 Autopilot and Multi-Function Display
• Simrad Class D VHF Radio Telephone with DSC and Separate Antenna
• Yacht Controller
• NAVIOP Monitoring and Control System (Push Button)
• Synoptic Panel
• Windlass Controls
• C-Top Controls
• Hydraulic Bow and Stern Thruster Controls (ABT)
• Vessel View
• Analog Gauges
• Compass
• Fusion Stereo

• Anchor/Mast/Stern Lights
• Navigation Lights
• 48mi Radar
• VHF and Furuno GP-330B GPS Antenna
• FLIR Thermal Camera
• Horn
• KVH M7 HD SAT TV Dome
• Weather Antenna
• Search Light
• Two Life Rafts (4 Person and 6 Person)

The convertible “C-Top” allows the 88 Riva to function as both an open or coupé. It is moved by a pantograph
mechanism that guides a double pair of arms connected to the top. It is then fastened by electro-hydraulic locks in
the hard top and a mechanical joint in windshield.
The C-Top has three different positions: as a hard top for the main deck, half way up as a sunshade for the foredeck,
or down, enclosing the foredeck seating area.
Custom inserts were made to enclose the hard top to the windshield sides when in the coupé position. This prevents
any rain or spray to enter the helm deck, while still maintaining the sleek Riva lines.

Foredeck:
• U-shaped sofa (when C-TOP is up)
• (2) Watertight Loudspeakers Connected to the Stereo in the Lounge
• VIP Cabin Skylight
• Sun Pad

• Hydraulic Bow Thruster (40HP)
• (2) 2700W Lofrans Windlass Winches with 2 Mooring Cleats
• Two Bow Anchors in Polished SS: Primary Anchor (50 Kg) with 300’ of Galvanized Steel Chain (12mm);
• Secondary Anchor (30 Kg) with 250’ of Galvanized Steel Chain (12mm)
• Fresh/Saltwater Washdowns and Firefighting Hose
• SS Bow Rail and Rub Rail
• SS Hawses and Fairleads

Walking down 7 steps from main deck (custom built SS hand rail added by captain), you enter the spacious salon
with almost 7’ of headroom. The lower deck is kept cool by the upgraded Super Tropical 108,000 BTU air conditioning
system. There is a beautiful combination of vintage and contemporary decor throughout inspired by Rivas of the 1980’s and
1990’s, including elm, leather, lacquered surfaces, and steel. The elm wood finished in a matte velvet “peach skin”,
which feels soft to the touch and provides the senses with both a visual and tactile contrast to the polished steel
highlights. Plenty of storage space can be found under the sole, which is open from the galley area forward through the companionway. This is also where the blackwater, greywater, and freshwater tanks are located.

Salon:
• Samsung 46” LED TV
• Large Hull Side Windows
• Carpeted Floor with Padding Underneath
• Coffee Table
• Hi-Fi System with Ceiling Speakers
• L-Shaped Settee
• Stainless Steel Handrail and Ladder with Anti-Slip Surface Wooden Steps to
• Access Below Deck
• Venetian Blinds
• LED Lighting
• Smoke Detector

Galley:
• Open Bar with 2 Stools
• “Side by Side” Refrigerator and Freezer
• Combined Electric and Microwave Oven
• Ceramic Cooktop
• Dishwasher
• Large Hull Side Window
• Extractor Hood with Direct Outboard Discharge
• Glossy Lacquered Ceiling
• Porthole Housing with Venetian blinds
• Washbasin with Mixer Tap

Master Stateroom
• King-Size Bed
• 2 Large Windows and Porthole
• Bookshelves, Dressing Table, Wall of Hanging Lockers, and
• Bed Frame Upholstered in Sole Leather
• Carpeted Flooring with Padding Underneath
• (2) Drawer Under the Bed
• Hi-Fi System
• Samsung LED TV 32”
• Mirror
• Open Compartments with Wooden Shelves and Glossy Stainless Steel Anti-Rolling Rail
• Porthole Housing with Venetian Blinds and Black Out Blinds
• Reading Lights (2)
• Safe
• Smoke Detector
• Stainless Steel Handrail and Ladder with Wooden Steps with Carpet
• Vanity with Mirror and Pouf
• (4) Wardrobe Doors with Courtesy Lights
• DirectTV, NAD Stereo, DVD Player, and Surround Sound
• The Single 1981gal Fuel Tank is Located Under the Master Stateroom Sole

Master Head:
• Bathroom accessories (Soap Holder, (2) Bathrobe Hangers, Toilet Paper Holder, Toilet •
Brush Holder and Glass for Toothbrushes)
• Large Window and Port Hole
• Black Water Tank Level Indicator Integrated in the Toilet Control Panel
• Electric Blower
• Electric Toilet and Bidet in Ceramic
• Shower Compartment with Stainless Steel and Glass Door

VIP Stateroom
• Queen Bed with Frame Upholstered in Sole Leather
• Carpeted Flooring with Padding Underneath
• Drawer Under the Bed
• LED TV 22”
• Skylight Above with Emergency Access to Bow
• Mini Hi-Fi CD/DVD
• Mirror
• Reading Lights (2)

VIP Head:
• Bathroom Accessories (Towel rail, Soap holder, (2) Bathrobe Hangers, Toilet Paper Holder, Toilet Brush Holder and
Glass for Toothbrushes)
• Black Water Tank Level Indicator Integrated in the Toilet Control Panel
• Electric Ceramic Toilet/Bidet
• Electric Blower
• Lighting
• Mirror
• Shower Unit with Glass and Stainless Steel Door

Guest Cabins
Port Side Guest Cabin::
• Queen Bed with Frame Upholstered in Sole Leather
• Drawer Under the Beds
• Samsung TV
• Extinguisher
• Headboard Upholstered in Sole Leather
• Lighting
• Mini Hi-Fi CD/DVD
• Mirror
• Porthole Housing with Venetian Blinds and Black Out Blinds
• Telephone
• Wardrobe with Courtesy Lights
• Wooden Nightstands (2)

Guest Head:
• Bathroom Accessories (Towel Rail, Soap Holder, Toilet Paper Holder, Toilet Brush Holder and Glass for
Toothbrushes)
• Black Water Tank Level Indicator Integrated in the Toilet Control Panel
• Corian Floor, Washbasin Top
• Electric Ceramic Toilet/Bidet
• Electric Blower
• Lighting
• Mirror
• Porthole Housing with Venetian Blinds
• Shower Unit with Glass and Stainless Steel Door
• Wooden Bulkheads and Cabinets with Matte Varnish and Laminate
Starboard Side Guest Stateroom:
• Twin Beds with Drawers Underneath
• Carpeted Floor with Padding Underneath
• Mini Hi-Fi CD/DVD

Guest Head (Day Head, Starboard Side):
• Additional Access from Lower Deck Lobby
• Bathroom Accessories (Towel Rail, Soap Holder, (2) Bathrobe Hangers, Toilet
• Paper Holder, Toilet Brush Holder and Glass for Toothbrushes)
• Black Water Tank Level Indicator Integrated in the Toilet Control Panel
• Electric Ceramic Toilet/Bidet
• Electric Blower
• Mirror
• Shower compartment with Round Plexiglass Sliding Doors

Crew Quarters

Crew Lobby:
• General Electric Breaker Panel
• Carpeted Flooring with Padding Underneath
• CCTV Infrared Color Camera (2)
• 24V Fridge, Sink and Cook Top and Pan Holder
• Sofa (2)
• Table

Crew Cabin:
• Bunk Beds with Mattress, Pillow and Bedspreads
• Carpeted Flooring with Padding Underneath
• Mini Hi-fi
• Carpeted Flooring with Padding Underneath
• Folding Worktop
• Wardrobe
• Washer/Dryer Machine

Crew Head:
• Black Water Tank Level Indicator Integrated in the Toilet Control Panel
• Cabinets and Shelves
• Electric Ceramic Toilet/Bidet
• Electric Blower
• Fiberglass Flooring
• Mirror
• Shower and Waterproof Curtain
• Stainless Steel Wash Basin with Mixer Tap

• Twin Mitubishi ARG Stabilizers: contrary to SeaKeeper models, the ARG does not have a cooling loop – it self
cools, and does not require regular maintenance. It is only suggested that you visually inspect the ARG annually.
Mitsubishi claims that its design is less complex and in turn less expensive to run than its competitors.
• MTU 16V2000 M96L 2,638HP Each
• ZF 3070A V-Drives with Power Take Off for Bow/Stern Thruster
• Twin Kohler 23kW/60hZ EOZD Generators - 1640 hours
• Power Take Off for Bow/Stern Thrusters
• Air Compressor to Stbd for Horn
• Marco Air Compressor
• Lead Acid Batteries Outboard of Engines
• Water Maker
• TNT Spot Fee Filtration System for Rinsing
• Racor Generator Filters
• Acoustic and Thermal Insulation
• Air Inlets (2)
• CCTV Infrared Color Camera (2)
• Engine Cooling Water Filters (2)
• Floor in Anti-Slip Light Alloy
• Fuel-Water Separator Filters with Alarms
• Stainless Steel Stair for Access to Engine Room from Main Deck
• Watertight Door Access from Crew Quarters
• Automatic Extinguisher with External Control
• Hot Water System with Two 80 Liter Boilers

• (2) 100amp Shore Power Cords
• MASS 24/75 Mastervolt Battery Charger
• Mass Sine 24/1500 Inverter
• 110 V outlets Throughout
• Battery Groups and Chargers for Engines, Services, and Generators,
• Battery Parallel Facility for Engine Start-up
• Cathodic Corrosion Protection with Zinc Anodes
• Fuse Panel
• Inverter for Refrigerators Power Supply
• Inverter for Services
• Manual Battery Switch for Generator (2)

New Teak Swim platform installed 2024

• Hydraulic Swim Platform
• Concealed SS Electro-Hydraulic Gangway with Automatic Stanchions and Teak Flooring;
Custom-Built 90º Gangway Extension Allows for Easy Boarding from Side of Vessel
• Concealed SS Electro-Hydraulic Swimming Ladder Built Into the Stern
• Electro-Hydraulic Fiberglass Hatch for Tender Garage
• Tender Garage; Remote Controlled Launching System for the Aquascan Tender and Jet- Ski with Custom Welded
Inserts Extending the Track for Smoother, Safer Operation
• Freshwater Inlet and Waste Outlet
• Hot/Cold Shower
• Cleats Were Relocated Further Aft for Easier Boarding
• In-Deck Storage Hatches Added to Sides of Swim Platform
• Manual Emergency Ladder

• (8) Under Water Lights (2 Aft, 3 on Each Hull Side)
• 5-Bladed Props
• Stern Thruster (40HP)
• Trim Tabs
• Echo Transducer
