Odyssey Lll Yacht for Sale | 32 Legacy Yachts Greenport, NY

Hull and Deck

The hull is constructed using Legacy's Durahull technology. The deck, hull and all structural components are infused Vinylester construction. The centerline and leading edge of the keel are reinforced with Kevlar TM for impact resistance. All thru hull penetrations are designed to isolate the core materials from water penetration. Hull and deck are cored with Corecell TM. Underwater exhaust and thruster tubes are molded into the hull.

Bridge Deck

The custom designed Helm Station is finished with varnished teak. It provides full engine instrumentation including Smart Craft, auxiliary switch panel, flush electronics mounting and a tilting 16" wood and stainless-steel steering wheel. The trim tab controls, and bow and stern thruster controls are to starboard. There are twin Stidd helm seats with two settees port and starboard with top access storage below. A removable Teak table installs between the settees. Two stainless steel pillars support the aft end of the cabin top. The headliner is foam backed vinyl and easily removable for wiring access. The Bridge Deck is Air Conditioned. Standard ventilation can be provided by the two opening overhead hatches, an opening center pane of the windshield and sliding side windows. The Bridge Deck and Cockpit sole are Teak with access hatches for the engine room and aft storage.

Electronics and Electrical

Smart Craft Engine Monitoring
Glendinning Engine Controller
Side Power Bow and Stern Thruster
Lenco Trim Tab Control
Raymarine GPS Chart plotter
Raymarine Radar
Raymarine Smart Pilot Autopilot
Raymarine Knot Meter
Raymarine Depth Sounder
Icom IC-M405 VHF Radio
Mastervolt Battery Charger
Mastervolt Masterlink System
Onam Cummins powered Genset
Dual Hubbell Shoreguard Shore Power Connections
2,500 Watt Inverter
Maxwell Windlass
Air Conditioning Cabin and Bridge Deck
Pompanette AC Controllers
Rule Automatic Bilge Pumps
Powered Spotlight
Stereo
15" LCD TV

Interior

The interior is finished in a varnished Cherry: bulkheads, trim and cabinetry. The cabin sole is Teak and Holly. Cabinets, lockers, cabin door frames, drawer faces and frames are solid wood. Positive catch hardware on all the drawers and doors. The interior is warm and inviting. The interior is fully Air Conditioned, well-lit and well-ventilated with the addition of opening hatches and stainless-steel opening port lights.

Master Berth

Queen sized island berth with two pull-out drawers below. Hanging locker on the port side of the cabin. Locker with shelves on the starboard side. Full length shelves on both sides of the berth. Upholstered Ultraleather headboard.

Galley

U-shaped galley with opening door outboard and an opening rounded counter island. Deep stainless-steel sink with pull out facet head. Stainless steel refrigerator draw 12V DC under counter. Electric two-burner cooktop set into the countertop with countertop filler. Microwave oven installed above the sink.

Head and Shower

The head sink is stainless steel with a single lever hot/cold facet. The sink base has additional storage below and a vanity cabinet beside. A hamper and towel locker are located the outboard side of the toilet and shower. There is also a gasketed dry locker. A Jabsco Quiet Flush Electric Head with discharge to a holding tank. A separate shower compartment with a clear self-latching door, massaging-type shower head on a sliding bar. Recessed shower grate and remote pump for shower sump drainage.

Cockpit

A center-mounted Transom door with stainless steel hinges and latch allows access to the full transom swim platform with fold down swim ladder. A stern settee with removeable center section, dual cup holders and a removeable cockpit table add addition seating options. The Teak cockpit sole has additional opening hatches for below deck storage and access. A removable Bimini top shades the area if desired.

Additional Information

The vessel is constructed to meet or exceed ABYC and NMMA standards.
Solid bronze seacocks
Thru hull fittings are stainless steel double clamped above the waterline
Thru hull fittings are bronze double clamped below the waterline
Engine room surfaces sound insulated
Hatches are gasket sealed
All machinery vibration dampened
Engine mounts are flexible rubber drilled and tapped into steel reinforced stringers
Aquanet shaft tapered and keyed to match coupling
PBS dripless shaft seals
Flangeless brass and rubber cutlass bearing pressed into stern tube
CNC machined Nibral propeller custom-designed to match engine output
Cast manganese bronze rudder with stainless steel shaft
Tides Marine composite dripless rudder bearing and seal assembly
Hydraulic steering with pressurized reservoir and high-pressure tubing
Glendinning electronic control with low speed idle for docking
