STEALTH Yacht for Sale

• Cruising Speed: 15 kn
• Maximum Speed: 27 kn
• Beam: 27' 7''
• Hull Material: Aluminum
• Max Draft: 5' 7''
• Fuel Tank: 1 x 9554|gallon
• Fresh Water: 1 x 1616|gallon
• Holding: 1 x 799|gallon
• Cabins: 5
• Heads: 5

Accommodation for up to 12 guests in 5 cabins as follows:

Owner:

•  1 x Master with ensuite bathroom on the main deck

Guests:

• 2 x Double cabins with ensuite bathrooms
• 2 x Twin cabins with ensuite bathrooms and 2 x Pullman berths

Crew:

•  Up to 9 Crew in 5 Cabins

• Range:Miele Professional series KM5773
• Oven:Gaggenau-(top) BO420112 400, (Bottom) BO451610 400
• Microwave: Gaggenau BM2411110
• Refrigeration: Bush Refrigeration custom-made walk-in/Sub Zero 700TR
• Freezer: Sub Zero 700TF
• Small Fridge: Salon Bar – Frigonautica FRS160AC
• Wine Cooler: Frigonautica FC/3
• Icemakers: 2 x Hoshizaki, 1 x 280lb ice maker
• Dishwasher: Miele
• Garbage Disposal: Yes
• Main Laundry: 2 x Miele PW 6065 Plus Washers & 2 x Miele PT 7135C Plus Dryers
• Main Deck Pantry: 1x Drawer Dishwasher

TV/ DVD:

• 2 x Intellian S100HD WorldView HDTV
• 10 x Direct TV US Receivers, Kaleidescape system

Music  System:

• Creston integrated
• iPad controls with whole boat audio

Internet:

• StarLink High-Speed Internet, Full Wifi throughout the vessel

• 2 x Desktop Computers & Samsung Screens
• 1 x HP Laserjet MFP M281fdw Copier/Printer

• Anchors: 2 x Kedge 175KG
• Anchor Chains: 2 x 137.5m Grade 2A 17.5mm
• Windlasses: 2 x Maxwell VWC/LP800 AC
• Stern Capstans: 2 x Maxwell VC/6000 AC
• Passarelle: Sanguineti Shavari (Mizar Grande 3 Sfili)
• Ladders: Sanguineti Shavarin(Scalletta Bagno STD)
• Boat Crane/Davits: 1 x 5PT20 2,000 LB SWL
• Ground Tackle: Port 6 shots 30m Stbd 4 shots 30m
• Spotlights: ACR Searchlights
• Jacuzzi: Located on sundeck - brand new Jan 2024
• Barbecue: GaggenauElectric Grill
• Exterior Showers: (1) on the swim platform
• Swim Ladders: (1) Inox with teak steps

• Main Engines:2 x MTU 16V4000, 3,650hp each
• Engine Hours (01/24) - Port - 5640  hours | Starboard - 5640 hours
• Drive: Shaft Propeller
• Shafts: Stern tube and Single leg bronze “P” strut. Strut and stern tube water-lubricated bearings. Tides Marine dripless Sure Seal with crossover tube. The shafts were pulled and coupling and prop shaft tapers were Dynaflux dye penetrant checked as well as bearings replaced during the 10-year LR Special. Dry dock survey in August 2020. The running gear is coated with PropSpeed coating.
• Propellers: Rolla NiBrAl  60.05” 5 Blade
• Engine Controls: MTU controls
• Gear Boxes: ZF Gearbox ZF 7550 3.074/1 Ratio
• Steering System: Jastram Model: JQ061015-31
• Emergency Steering: Jastram Model: JA301002-3
• Engine Ventilation: Delta-T Model #: 610-MCE-P/T4 Serial #: 33212  - Port & starboard axial flow 7.5HP 30” reversible supply fans – both on Yaskawa V1000 variable frequency drives -10hp. Port & Starboard axial flow 2HP 19” reversible exhaust fans – both on Yaskawa V1000 variable frequency drives-2hp. System works off of pressure, temperature, auto & manual control.
• Watertight Doors: Yes
• Range: 1500 nm @ 12 knots

• Generators:Generators: 2 x Kohler 99kW
• Generator Hours (01/24): Port - 17,500 hours | Starboard - 18,600 hours
• Starboard gen to end rebuilt at 13k hours and port top end rebuilt at 10,700 hours
• Bow Thruster: Arcturus Marine (TRAC) 20-inch up to 100hp
• Stabilizers: ABT TRAC
• Electricity: 405/230V, 50Hz
• Shore Power: Converter ASEA Power Systems AC90V-3/2
• Batteries & UPS:
• Start 2 x 24v Bank, 8 x 12VDC 100Ah
• Service 1 x 24V Bank, 2 x 12VDC 255 Ah
• Emergency 1 x 24V Bank, 2 x 12VDC 255Ah
• Emergency 2 x 24V Bank, 2 x 12VDC 100Ah

• Air Conditioning: Cruisair 3 x Scroll Compressors
• A/C Sea Water Pumps: Marathon, Cruisair
• A/C Fresh Water Pumps: Marathon, Cruisair
• Air Compressor: Jun-Air 30 Gal
• Freshwater System: 2x Gianneschi
• Fresh Water Filters: Flow MAx cartridge UV light Sterilizer filters replaced Nov 2022
• Fresh Water Maker: Idromar HEM Hydro Electric Marine Mc5 Duplex
• Fuel Filters: 2x Separ SWK 2000/40
• Fuel Separator: Alfa Laval MAB-104B
• Rudder Angle Indicator: Pilothouse and wing stations
• Fuel Transfer Pumps: 1 x Oberdorfer gear wheel fuel transfer pump
• Fire/Bilge Pump: MP 21865 / Emergency fire Yanmar L100V6
• Lube Oil System: 1 x Oberdorfer N9090R gearwheel transfer pump for both clean and waste oil
• Sewage Treatment System: Hamman AG HL-Cont. Compact Mini, 400vac, 50Hz
• Grey Water Transfer Pump: Hamann AG HL, Cont. MEPC 2(VI) Compact Mini treatment system, 4 pumps in this system are a USCG type II approved unit
• Toilet System: Tecma Flexi Line 2G
• Under Water Lights: Transom - 5 Hull sides - 2
• Boilers: Hubbel 2 x 50 gallons

• Gross Tonnage: 395 GT
• Net Tonnage: 118 NT
• Displacement Light Ship: 228.84 metric tonnes
• Displacement Full Load:  296 MT
• Fuel Capacity:  9,554 USG / 36,167 LT
• Fresh Water Capacity: 1,616 USG / 6,117 LT
• Grey & Black Water: 799 USG / 3,024 LT
• Water Makers: Idromar International Model MC-5 Duplex
• Clean Lube Oil: 615USG / 2,328LT
• Dirty Lube Oil: 615USG / 2,328LT
• Day Tank: 1945 USG / 7364 LT

• Life jackets:
• 12x Crew saver Adult 275Ns
• 2x Remploy Falgo 275N
• 16x Stearns Adult USCG Approved Offshore PDF
• 3x Stearns Child USCG Approved
• Life Rafts: Viking 12DK+ 12 person
• EPIRB: ACR 406Mhz 1322A
• Firefighting Equipment:
• 23x Fire extinguishers
• Fixed NOVEC system for ER
• Fixed sprinklers throughout the vessel
• 2x Drager firefighting sets
• 6x Drager SCBA Tanks
• Ship Alarms: Night watch system
• Bilge & fire pumps:
• MP 21865
• Emergency fire Yanmar L100V6
• Searchlight:2x ACR RCL-600A
• Security cameras: 8 x Axis Dome Network Camera (1 M3058-PLVE, 5 M5525-E, 1 Q6135-LE, 1 Mast Camera)
• Ship safes: Honeywell

• SAT com: VSAT – KVH V11, STARLINK
• VHF System: 2 x Furuno and 1 x Simrad AR78 and 2 x VHF Handheld & SSB Radio Furuno
• Printer/Fax: Furuno
• Ships Computer: Time zero

• Radar: 2 x Furuno RCU-014
• Magnetic Compass: Ritchie FN-201
• GYRO Compass: Simrad AR78
• Auto Pilot: Simrad AP50
• Log: Furuno GP-150
• GPS: Furuno GPS Navigator GP-150
• Displays: 3 New AYDIN displays
• AIS: Furuno FA1501 Universal AIS
• Chart Plotter: Nobeltec Timezero
• Depth Sounder:B&G
• Navtex: Furuno RCU-014
• Wind Instruments: B & G
• Weather Fax:  Furuno DFAX-207
• Speed Indicator:  Simrad

Tender:

• 39' 2018 SeaVee
• 2021 BRIG E3.5 with Honda 50HP

Toys:

• 2 X 2021 Sea-Doo RXP 300
• 2 X 2021 F5 Seabob
• Sealion
• Paddle Boards
• Snorkel and Fishing Gear
• Tube and Wake Surfing Equipment
• Custom inflatable beach club/jet ski docks
• Brownies dive compressor with tanks and gear for 12
• Snooba system on board for non-divers.

Refit in 2021-22 with fresh soft furnishings, mechanical upgrades, and the newest entertainment systems, STEALTH presents a true turn-key purchase opportunity.

2021

• AV / IT overhaul (New TV domes, IPAD system, speakers, internet, TV’s)
• CCTV replacement
• NAV / Helm upgrades (new monitors, radar/gyro service)
• Gens top-end rebuilds, engine service
• New Toys (tender, skis, seabobs, misc.)
• New crane system for tender garage
• Paint refurb, 3-step polish, and seal the entire boat
• A/C upgrades, replacement, and service of air handlers
• Interior / exterior soft goods (custom master settee, various new furniture, crew beds, plus new sheets, towels, misc. accessories)
• Systems service and rebuilds, Hamman, Delta-T, ASEA, Alfa Laval fuel centrifuge

2022

• Bottom sandblast to bare metal, prim, and bottom paint
• Main engine Exhaust full replacement
• Main engine service (reseal exhaust, turbo housings, machine exhaust manifolds)
• paint touch up / polish and seal
• Replace exterior cushions
• Hydraulic system flush and service
• Starlink install for easy, fast internet
• Galley equipment replacements (stove, oven, microwave)
• Systems service and rebuilds, centric screw pump, ASEA, alfa lav, water makers
• helm chairs and settee leather replacement

2023

• HVAC units and ducts full cleaning and sanitization
• topside paint polish and seal
